Products Description :

Suitable for A.C – AAC – ACSR and copper conductors.
Made of hot forged, heat treated, and cadmium plated high tensile alloy steel.
A complete range of interchangeable aluminum liners allows the clamp to fi t the exact conductor diameter.
Each model of Clamp is suitable for a wide range of conductors, therefore, the same clamp can be used for
different projects only by replacing aluminum liners.
NOTE: Upon placing the purchase order, please specify Conductor’s overall diameter.

Products Details :

Safety Note : Automatic negative brake engages every time the control lever on Tensioner/Puller is released.

– Hydraulic motor with quick release power in-lets
– Idle position for reel rotation and manual adjustment of spooler rope-guiding unit
– Standard connecting hoses set, 10 m length (other lengths upon request)
– Folding arm, wheels with extractable axle and towing bar for ease of transport.
– Upper lifting balanced attachment point and anchoring attachments
– Weight: 300 Kg.
– Overall dimensions: 760 x 1350 x 1480 mm
– Max torque: 100 daN m
– Operative pressure: 150 bar
– Max lifting capacity: 2000 Kg
