Products Description :
Hydraulic Bus Bar Cutter & Benders for Aluminium, Copper and Iron Materials
Products Details :
1. Model No. HYSC-24
Length : 360 mm
Weight : 2.6 kgs
■ Specifications :
Max pressure : 700 bar
Oil required : 25 cc
Max output : 7.45 tons / 66.3 kN
■ Cutting capacity :
Wire rope 6×7 : 24 mm
Wire rope 6×12 : 24 mm
Wire rope 6×19 : 24 mm
Soft copper bar : 23 mm
Soft aluminum bar : 24 mm
Soft steel bar : 16 mm
Cu strands : 24 mm
Al strands : 24 mm
ACSR : 24 mm
※Note: Tensile strength (daN/mm²≦180)
※Cutting of piano wire is prohibited.
■ Features :
180˚ rotating head for convenient operation.
Superior guillotine type cutting for less jamming than shear type cutters.
Single stage pumping action.
All blades are easily replaceable.
Flip-top latch for easy insertion of cutting material.
Single stage pump action with spring return.
No set-up time required.
Lightweight, self-contained tool, can be used anywhere.
■ Accessories :
Carrying bag
2. Model No. HYSC-45
Length : 683 mm
Weight : 6.7 kgs
■ Specifications :
Max pressure : 700 bar
Oil required : 70 cc
Max output : 10.73 tons / 95.5 kN
■ Cutting capacity :
Wire rope 6×7 : 40 mm
Wire rope 6×12 : 40 mm
Wire rope 6×19 : 40 mm
Soft copper bar : 32 mm
Soft aluminum bar : 40 mm
Soft steel bar : 20 mm
Cu strands : 40 mm
Al strands : 40 mm
ACSR : 40 mm
※Cutting of piano wire is prohibited.
■ Features :
Light weight portable hydraulic cutter features.
Single action cylinder with spring return.
Guillotine type cutting for less jamming than shear type cutting.
No set-up time required.
Blades are easily replaceable.
180˚ swivel and lock pin type head allows easy cutting position.
■ Accessories :
Carrying bag
3. Model No. S-55
Length : 631 mm
Weight : 10.3 kgs
■ Specifications :
Max pressure : 700 bar
Oil required : 107 cc
Max output : 14.01 tons / 124.6 kN
■ Cutting capacity :
Wire rope 6×7 : 25 mm
Wire rope 6×12 : 30 mm
Wire rope 6×19 : 30 mm
Soft copper bar : 35 mm
Soft aluminum bar : 28 mm
Soft steel bar : 19 mm
Cu strands : 54 mm
Al strands : 54 mm
ACSR : 54 mm
Guy wire 1×7 : 15 mm
Guy wire 1×19 : 20 mm
Underground cable : 50 mm
※Cutting of piano wire is prohibited.
■ Features :
Light weight portable hydraulic cutter features.
Single action cylinder with spring return.
Guillotine type cutting for less jamming than shear type cutting.
No set-up time required.
Blades are easily replaceable.
180˚ swivel and lock pin type head allows easy cutting position.
■ Accessories :
Carrying bag
4. Model No. HYSC-85YC
Length : 694 mm
Weight : 8.7 kgs
■ Specifications :
Max pressure : 700 bar
Oil required : 80 cc
Max output : 8.32 tons / 74.0 kN
■ Cutting capacity :
Cu strands : 60 mm
Al strands : 60 mm
CCP cable : 85 mm
Underground cable : 85mm (except armoured cable)
※Cutting of piano wire is prohibited.
■ Features :
Fast cutting with remote operation
Two stage pumping action for rapid blade advance
180˚ rotating head plus an extra handle for easy carry and overhead convenient operation.
No set-up time required.
■ Accessories :
Carrying bag
