TEMA – Hydraulic Puller Tensioner 90 kN – AF158.12

Name: TEMA - Hydraulic Puller Tensioner 90 kN - AF158.12
SKU: 381f0d21ce52
Availability: InStock

TEMA – Hydraulic Puller Tensioner 90 kN – AF158.12

Rp0.00

Standard features
– 1 hydraulic circuit with negative brake system
– 1 dynamometer for direct reading of pulling value with load-limiter
device (puller-mode)
– 1 Counter-meter device
– 2 sets of quick-release hydraulic connectors to drive up to 2
hydraulic driven reel-stands or reel-winder units
– Thermally treated steel adherence wheels
– Gear box (2 speed)
– Wired remote control unit c/w console
– Hydraulic stabilizers
– Rigid axle with tyres for towing up to 30 km/h
– Balanced top lifting point and anchoring attachments

Download File

Order on Whatsapp

SKU: 381f0d21ce52 Categories: Machine for Tower Erection and Stringing Operation, Puller-Tensioners Tag: Hydraulic Puller Tensioner 90-95 kN

Description
Brand

Products Description :

Hydraulic Puller-Tensioner 90-95 KN Capacity For Bundle Conductor as Well as OPGW Cable Stringing Operations

Products Details :

Puller Performance
Max pull 90 kN
Speed at max pull 2,2 km/h
Max speed 5 km/h
Pull at max speed 40 kN

Tensioner Performance
Max tension 90 kN
Max speed 5 km/h

Characteristics
Adherence-wheels Diameter 1500 mm
Max conductor diameter 40 mm
Max rope diameter 24 mm
Weight 5000 kg

Engine
Diesel (125 Hp) 93 kW
Cooling Liquid
Starter Electrical

Optional Equipment
01-PT Preset for digital data recorder, counter-meter and
speedometer
04-PT Wireless remote control unit c/w console
07-PT Hydraulic power take-off for press
08-PT Conductor/rope holder clamp (hydraulic)
15-PT Adherence wheels with interchangeable Nylon liners
18-PT Multiple connection preset

Special features upon request
02-PT Dynamic speed pulling force control
05-PT Additional hydraulic power take-off on reel-winder circuit
20-PT Pre-heater (up to -30°C)
