TEMA – Hydraulic Puller Tensioner 70 kN – AF156.12

Name: TEMA - Hydraulic Puller Tensioner 70 kN - AF156.12
SKU: 40595d073546
Availability: InStock

TEMA – Hydraulic Puller Tensioner 70 kN – AF156.12

Rp0.00

Standard features
– 1 hydraulic circuit with negative brake system
– 1 dynamometer for direct reading of pulling value with load-limiter device (puller-mode)
– 1 Counter-meter device
– 2 sets of quick release hydraulic connectors to feed up to 2 remote reel-stands or reel-winder units
– Thermally treated steel adherence wheels
– Gear box (2 speed)
– Wired remote control unit c/w console
– Mechanical stabilizers
– Rigid axle with tyres for towing up to 30 km/h
– Balanced top lifting point and anchoring attachments

Download File

Order on Whatsapp

SKU: 40595d073546 Categories: Machine for Tower Erection and Stringing Operation, Puller-Tensioners Tag: Hydraulic Puller Tensioner 70-75 kN

Description
Brand

Products Description :

Hydraulic Puller-Tensioner 70-75 KN Capacity For Bundle Conductor Stringing Operations

Products Details :

Puller Performance
Max pull 70 kN
Speed at max pull 1,9 km/h
Max speed 5 km/h
Pull at max speed 26 kN

Tensioner Performance
Max tension 70 kN
Max speed 5 km/h

Characteristics
Adherence-wheels Diameter 1500 mm
Max conductor diameter 40 mm
Max rope diameter 18 mm
Weight 4400 kg

Engine
Diesel (85 Hp) 63 kW
Cooling Liquid
Starter Electrical

Optional Equipment
01-PT Preset for digital data recorder, counter-meter and
speedometer
04-PT Wireless remote control unit c/w console
07-PT Hydraulic power take-off for press
08-PT Conductor/rope holder clamp (hydraulic)
15-PT Adherence wheels with interchangeable Nylon liners
18-PT Multiple connection preset

Special features upon request
02-PT Dynamic speed pulling force control
05-PT Additional hydraulic power take-off on reel-winder circuit
20-PT Pre-heater (up to -30°C)
