TEMA – Hydraulic Tensioner 150 kN – FA1514.12

Name: TEMA - Hydraulic Tensioner 150 kN - FA1514.12
SKU: 3c499fad9773
Availability: InStock

TEMA – Hydraulic Tensioner 150 kN – FA1514.12

Rp0.00

Standard features
– 1 hydraulic circuit with negative brake system
– 1 dynamometer for direct reading of pulling value
with load-limiter device (puller-mode)
– 1 Counter-meter device
– 1 set of quick-release hydraulic connectors to drive
up to 4 hydraulic driven reel-stands or 1 reel-winder unit
– Adherence wheels with interchangeable Nylon liners
– Rear independent hydraulic stabilizers
– Rigid axle with tyres for towing up to 30 km/h
– Balanced top lifting point and anchoring attachements

Order on Whatsapp

SKU: 3c499fad9773 Categories: Machine for Tower Erection and Stringing Operation, Tensioners Tag: Hydraulic Tensioner 150 kN

Description
Brand

Products Description :

Hydraulic Tensioner-Puller 150 KN Capacity For Single/Bundled Conductors Stringing Operations

Products Details :

Tensioner Performance
Max tension 150kN
Max speed 5 km/h

Pull-back Performance
Max pull 150 kN
Max speed 0,6 km/h

Characteristics
Adherence-wheels Diameter 1500 mm
Max conductor diameter 40 mm
Weight 8800 kg

Engine
Diesel (69 Hp) 51 kW
Cooling liquid
Starter Electrical

Optional Equipment
01-PT Preset for digital data recorder, counter-meter
and speedometer
07-PT Hydraulic power take-off for press
08-PT Conductor/rope holder clamp (hydraulic)
14-PT Thermally treated steel adherence wheels
18-PT Multiple connection preset

Special features upon request
20-PT Pre-heater (up to -30°C)
